ManualCallPoint
Wireless resettable manual call point with programmable scenarios, Jeweller radio, tamper protection, and up to 7 years battery life.
Online pricing for this product is unavailable due to supplier restrictions. Please contact us for an authorised quote.
Available Colours
ManualCallPoint
Overview
ManualCallPoint is a wireless, resettable manual call point designed for rapid activation of alarms and automation scenarios in critical situations. With Jeweller radio communication, programmable modes, and deep integration into the Ajax ecosystem, it can trigger fire alarms, run evacuation scenarios, and notify users and monitoring centres in seconds. The resettable frangible element and protective lid ensure reliability and prevent accidental activation.
Key Features
- Wireless resettable button with programmable scenarios
- Multiple operating modes: fire alarm, scenario trigger, auxiliary, panic, gas leak, malfunction, water leak
- Activates fire detectors built-in buzzers and intrusion sirens
- Supports complex automation chains: de-energising loads, unlocking exits, enabling ventilation, and emergency lighting
- Addressable events with time, location, and device details in Ajax apps and CMS
- Transparent front lid to prevent accidental presses
- LED indication for alarms and malfunctions
- Tamper alarm for removal or opening attempts
- Up to 1,700 m Jeweller radio range (extendable with ReX / ReX 2)
- Up to 7 years battery life on 2 x CR123A batteries
Ideal Applications
- Educational facilities and campuses
- Business centres and office buildings
- Industrial premises and warehouses
- Public spaces and commercial venues
- Any site requiring manual fire alarm activation and emergency automation
System Integration
ManualCallPoint is part of the Ajax ecosystem and works with hubs, range extenders, automation devices, cameras, and MotionCam detectors. In a fire scenario, it can trigger fire detectors buzzers, activate intrusion sirens, de-energise circuits via WallSwitch, and enable emergency lighting and exits via Relay. All events are logged with precise timestamps and device identifiers, providing clear records for incident analysis and compliance.
Reliability & Supervision
The button mechanism is simplified to minimise moving parts and reduce failure risk in emergencies. Each device undergoes factory testing, and the system continuously supervises its status via Jeweller. Automatic self-diagnostics, regular polling, and instant maintenance notifications ensure the device remains ready without requiring frequent manual tests. A tamper alarm reports attempts to remove or dismantle the device from its SmartBracket panel.
Installation & Maintenance
ManualCallPoint is designed for fast, non-invasive installation using the SmartBracket mounting panel - there is no need to disassemble the enclosure. Pairing with the hub is done via QR code in the Ajax apps, and all configuration and testing can be performed remotely. After activation, the button is reset using the included special key, which can be carried on a keyring by the responsible person. The system notifies in advance when the batteries approach end of life, ensuring long-term, predictable operation.
Specifications
| Operating Principle | Wireless resettable button for triggering alarms and automation scenarios |
| Operating Modes | Fire alarm, scenario trigger, auxiliary alarm, panic button, gas leak alarm, malfunction alert, water leak alarm |
| Use Cases | Fire alarm activation, emergency automation, evacuation support, CMS alarm delivery |
| Compatibility | Hub Plus, Hub 2 (2G/4G), Hub 2 Plus, Hub Hybrid (2G/4G), ReX, ReX 2 |
| Radio Technology | Jeweller two-way wireless communication |
| Radio Features | Block encryption with dynamic key, device authentication, frequency hopping, anti-sabotage |
| Radio Frequency Bands | 866.0–866.5 MHz, 868.0–868.6 MHz, 868.7–869.2 MHz, 905.0–926.5 MHz, 915.85–926.5 MHz, 921.0–922.0 MHz (depending on region) |
| Radio Range | Up to 1,700 m (open space), extendable via ReX / ReX 2 |
| Key Features | Resettable frangible element, transparent protective lid, LED status indication, critical alerts, automation scenarios, fire detector buzzer activation, intrusion siren activation |
| Interconnected Fire Alarms | Pressing the button can trigger built-in sirens of fire detectors in the system |
| Notifications | Critical push notifications, CMS events, detailed event log (500 recent events) |
| Sabotage Protection | Tamper alarm for removal or dismantling, device authentication, communication loss detection (from 36 s) |
| Special Tool | Key for button reset and device removal from SmartBracket |
| Installation Recommendations | Indoor use only, installed in accessible places at ~1.4 m height |
| Power Supply | 2 × CR123A batteries (pre-installed) |
| Battery Life | Up to 7 years (typical use: one press lasting 1 minute per week) |
| Self-Diagnostics | Automatic self-test, regular polling, maintenance notifications |
| Dimensions | 102 × 104 × 39 mm |
| Weight | 214 g (without packaging) |
| Operating Temperature | 0°C to +50°C |
| Operating Humidity | Up to 80% RH |
| Protection | Indoor use, protective transparent lid |
| Complete Set | ManualCallPoint Jeweller, SmartBracket mounting panel, special tool (key), 2 × CR123A batteries (pre-installed), installation kit, quick start guide |
| Warranty | 24 months |
