MotionProtect Jeweller
A wireless indoor PIR motion detector with up to 12 m detection range, pet immunity, SmartDetect false‑alarm filtering, and up to 5 years of battery life.
Online pricing for this product is unavailable due to supplier restrictions. Please contact us for an authorised quote.
Available Colours
MotionProtect Jeweller
A wireless indoor PIR motion detector designed for reliable intrusion detection in residential, commercial, and industrial environments. MotionProtect Jeweller combines advanced optics, intelligent software algorithms, and long‑range encrypted communication to deliver fast, accurate motion detection with minimal false alarms. It installs effortlessly using the SmartBracket mounting panel and operates for up to five years on a single pre‑installed battery.
Engineered for professional‑grade performance, the detector maintains accuracy across a wide temperature range, filters thermal interference, and provides pet immunity for animals up to 20 kg. With real‑time supervision, tamper protection, and remote configuration via Ajax apps, MotionProtect Jeweller ensures dependable protection with minimal maintenance.
Key Features
- Up to 12 m detection distance
- Horizontal 88.5° / vertical 80° viewing angles
- SmartDetect false‑alarm filtering algorithm
- Pet immunity up to 20 kg / 50 cm
- Up to 1,700 m wireless communication range with Jeweller protocol
- Encrypted two‑way communication with frequency hopping
- Up to 5 years of battery life from a single CR123A cell
- Tamper protection and spoofing detection
- Remote configuration and diagnostics via Ajax apps
- Effortless installation using SmartBracket and QR code pairing
How It Works
MotionProtect Jeweller uses a high‑quality PIR sensor paired with a specially engineered Fresnel lens to accurately distinguish human movement from pets, thermal noise, and environmental interference. The SmartDetect algorithm analyses IR patterns, movement speed, thermal spot size, and radiation intensity to eliminate false alarms while ensuring rapid response to real threats.
Temperature compensation maintains detection accuracy even when ambient temperatures approach human body temperature.
Installation & Placement
- Recommended installation height: 2.4 m
- Lens should be perpendicular to likely intrusion paths
- Suitable for indoor use only
- Pre‑installed battery and SmartBracket simplify mounting
When installed correctly, the detector ignores pets up to 20 kg and 50 cm in height.
Reliability & Supervision
MotionProtect Jeweller continuously communicates with the hub using encrypted two‑way radio. The system performs:
- Regular polling
- Tamper monitoring
- Communication loss detection (approx. 36 seconds at minimum interval)
- Automatic self‑diagnostics
These mechanisms ensure real‑time awareness of device status and immediate reporting of faults or sabotage attempts.
Compliance
- EN 50131 Grade 2
- PD 6662:2017
- UL Listed
Specifications
| Detection Distance | Up to 12 m when installed at 2.4 m height |
| Detection Angles | Horizontal 88.5°, Vertical 80° |
| Pet Immunity | Up to 20 kg / 50 cm height |
| Sensitive Element | PIR sensor |
| Sensitivity Levels | 3 levels, adjustable via Ajax app |
| False Alarm Prevention | SmartDetect algorithm |
| Temperature Compensation | Automatic compensation for stable detection |
| Communication Technology | Jeweller two‑way encrypted wireless protocol |
| Communication Range | Up to 1,700 m in open space |
| Frequency Bands | 868.0–868.6 MHz (region dependent) |
| Tamper Protection | Tamper alarm, spoofing protection, communication loss detection |
| Battery | 1 × CR123A (pre‑installed) |
| Battery Life | Up to 5 years |
| Operating Temperature | -10°C to +40°C |
| Operating Humidity | Up to 75% |
| Protection Class | IP30 |
| Dimensions | 110 × 65 × 50 mm |
| Weight | 86 g |
| Complete Set | MotionProtect Jeweller, SmartBracket, CR123A battery, installation kit, quick start guide |
| Compliance | EN 50131 Grade 2, PD 6662:2017, UL Listed |
