Superior MotionProtect Fibra
A wired indoor PIR motion detector with SmartDetect false‑alarm filtering, pet immunity, and long‑range encrypted Fibra communication.
Online pricing for this product is unavailable due to supplier restrictions. Please contact us for an authorised quote.
Available Colours
Superior MotionProtect Fibra
Superior MotionProtect Fibra is a wired indoor PIR motion detector engineered for high‑reliability intrusion detection. Using a precision Fresnel lens, a high‑quality PIR sensor, and the SmartDetect algorithm, it accurately identifies human movement while filtering out thermal noise, pets, and environmental interferences. Fibra wired communication ensures stable, encrypted connectivity over long distances, making it suitable for both residential and commercial installations.
Key Features
- Up to 12 m motion detection distance
- 88.5° horizontal viewing angle
- SmartDetect false‑alarm filtering
- Pet immunity up to 20 kg and 50 cm
- Fibra wired communication up to 2,000 m
- Low power consumption (up to 0.045 W)
- Temperature compensation for stable detection
- Remote configuration via Ajax apps
- Tamper alarm and short‑circuit protection
How It Works
Superior MotionProtect Fibra uses a PIR sensor to detect changes in infrared radiation caused by human movement. The Fresnel lens is engineered to differentiate between human IR signatures and environmental noise. SmartDetect software analyzes thermal patterns, movement speed, IR intensity, and object size to filter out false alarms. Fibra communication provides encrypted, two‑way data exchange with the hub, ensuring fast alarm delivery and continuous supervision.
Installation & Placement
- Designed for indoor installation only
- Recommended mounting height: 2.4 m
- Ideal for:
- Offices and commercial spaces
- Retail stores
- Residential properties
- Warehouses and industrial facilities
- Schools and medical centres
- Mounts using the SmartBracket panel with removable terminal board
- Supports cable routing through multiple perforated sections
Reliability & Supervision
- Tamper detection for enclosure opening and removal
- Short‑circuit protection on the Fibra line
- Device authentication prevents spoofing
- Encrypted communication with dynamic key protection
- Regular polling ensures real‑time device status
- Temperature compensation ensures consistent detection
- Low power consumption via TDMA scheduling
Compliance
- EN 50131 Grade 2
- PD 6662:2017
- INCERT
- SSF
- NFA2P
- Operating temperature: −10 °C to +40 °C
- Operating humidity: up to 75%
- Protection class: IP50
Specifications
| Product Type | Wired indoor PIR motion detector |
| Communication Technology | Fibra wired communication with encryption and device authentication |
| Line Requirements | 4‑core cable; up to 2,000 m using U/UTP Cat.5 (4×2×0.51 mm) cable |
| Alarm Type | PIR motion detection |
| Volume | N/A |
| Alarm Duration | N/A |
| Sound Frequency | N/A |
| Chime Feature | No |
| LED Features | Internal LED indication for identification and testing |
| Event Indication | Motion alarms, tamper alerts, communication faults |
| Tamper Protection | Tamper alarm for enclosure opening and removal; device authentication; short‑circuit protection |
| Backup Battery | N/A — powered from Fibra line |
| Power Supply | 5–30 V⎓, up to 0.045 W consumption |
| Installation Height | Recommended 2.4 m |
| Dimensions | 110 × 67 × 62 mm |
| Weight | Black: 75 g; White: 88 g |
| Operating Temperature | -10 °C to +40 °C |
| Operating Humidity | Up to 75% |
| Protection Class | IP50 |
| Colours | White, Black |
| Complete Set | Superior MotionProtect Fibra, SmartBracket mounting panel, installation kit, quick start guide |
| Compliance | EN 50131 Grade 2, PD 6662:2017, INCERT, SSF, NFA2P |
