Button Jeweller
A wireless panic and smart control button with configurable alarm types, accidental‑press protection, and long‑range encrypted communication.
Online pricing for this product is unavailable due to supplier restrictions. Please contact us for an authorised quote.
Available Colours
Button Jeweller
Button Jeweller is a wireless panic and smart control button designed for instant alarm transmission and rapid command execution. With configurable operating modes, accidental‑press protection, and long‑range encrypted communication, it provides a reliable way to raise alarms, trigger automation scenarios, or mute interconnected fire detectors. Compact and lightweight, it can be carried on a key ring, worn on a lanyard, or fixed to a surface using the optional Holder.
Key Features
- Three operating modes: Panic, Automation Control, Mute Fire Alarms
- Configurable alarm types including intrusion, fire, medical help, gas, leakage, malfunction, and custom
- Instant alarm transmission in under 0.15 seconds
- Accidental‑press protection with double‑press or long‑press activation
- Jeweller two‑way encrypted communication with up to 1,300 m range
- AES‑based encryption and device authentication
- IP55 protection for indoor and sheltered outdoor use
- Up to 5 years battery life on a single CR2032 cell
- Compact and portable for key rings, lanyards, or fixed mounting
How It Works
Button Jeweller communicates with an Ajax hub using the Jeweller radio protocol, ensuring fast and secure alarm delivery. In Panic mode, the button sends one of eight event types, each with its own CMS code and notification text. In Control mode, Button can activate one or multiple automation devices with short or long presses. The device is always ready to transmit — no wake‑up delay — and confirms successful delivery with a visual blink.
Installation & Placement
- Pair with the hub by scanning the QR code in the Ajax app
- Configure alarm type, operating mode, and press behaviour remotely
- Carry on a key ring, lanyard, or mount using Holder (sold separately)
- Suitable for homes, retail, offices, warehouses, and guard patrols
- Ideal for panic points, automation triggers, and fire alarm muting
Reliability & Supervision
- AES‑encrypted communication with frequency hopping
- Device authentication prevents spoofing
- Regular polling ensures continuous supervision
- IP55 enclosure protects against dust and splashes
- Accidental‑press prevention reduces false alarms
Compliance
- EN 50131 Grade 2
- SIA CP‑01
- UL Listed
- Operating humidity up to 75%
- Operating temperature from −10 °C to +40 °C
Specifications
| Product Type | Wireless panic button / smart button |
| Operating Modes | Panic, Automation Control, Mute Fire Alarms |
| Adjustable Alarm Types | Intrusion, Fire, Medical Help, Panic, Gas, Malfunction, Leakage, Custom |
| False Alarm Prevention | Double‑press or long‑press activation (configurable) |
| Communication Technology | Jeweller two‑way encrypted radio protocol |
| Radio Range | Up to 1,300 m in open space |
| Frequency Bands | 866.0–866.5, 868.0–868.6, 868.7–869.2, 905.0–926.5, 915.85–926.5, 921.0–922.0 MHz (region dependent) |
| Encryption | AES‑based block encryption, frequency hopping, device authentication |
| Alarm Transmission | ≤0.15 seconds, active from first click (no wake‑up required) |
| Power Supply | 1 × CR2032 battery (pre‑installed) |
| Battery Life | Up to 5 years |
| Operating Temperature | −10 °C to +40 °C |
| Operating Humidity | Up to 75% |
| Protection Class | IP55 |
| Dimensions | 47 × 35 × 13 mm |
| Weight | 16 g |
| Compatibility | All Ajax hubs and ReX range extenders (OS Malevich 2.7.102+) |
| Complete Set | Button Jeweller, CR2032 battery, double‑sided tape, quick start guide |
| Compliance | EN 50131 Grade 2, SIA CP‑01, UL Listed |
