Superior DoorProtect Fibra
A wired opening detector with dual reed switches, NC input, Chime support, and advanced Fibra communication for professional-grade intrusion protection.
Online pricing for this product is unavailable due to supplier restrictions. Please contact us for an authorised quote.
Available Colours
Superior DoorProtect Fibra
Superior DoorProtect Fibra is a wired opening detector designed for professional-grade intrusion protection. It uses two durable reed switches to detect door and window openings, allowing the magnet to be installed on either side of the detector. With advanced Fibra communication, an NC input for third‑party detectors, and strong anti‑sabotage protection, it delivers reliable perimeter security for commercial, industrial, and residential environments.
Key Features
- Two reed switches for flexible magnet placement
- Protection against contact chatter to prevent false alarms
- Two magnets included for various installation scenarios
- NC input for third‑party wired detectors
- Chime feature for door‑open notifications
- Up to 2,000 m wired communication via Fibra
- Two tamper buttons and holding screws for enhanced security
- Short‑circuit protection and device authentication
- Low power consumption (up to 0.036 W)
- Two matte colour options: white and black
How It Works
Superior DoorProtect Fibra uses two reed switches to detect the opening of doors, windows, and other access points. The magnet can be placed on either the left or right side, giving installers flexibility in cable routing and mounting. The detector communicates with the hub using encrypted Fibra wired technology, ensuring fast, stable, and secure data transmission.
The NC input allows integration of additional wired detectors, such as vibration, motion, or roller shutter sensors, expanding the protection zone. The Chime feature enables the detector to function as a doorbell when paired with an Ajax siren.
Installation & Placement
- Designed for indoor installation only
- Suitable for:
- Doors and windows
- Skylights
- Cabinets and restricted access areas
- Vaults and safes
- Install using the SmartBracket panel and holding screws
- Magnet can be mounted on either side of the detector
- Add to the system via automatic Fibra line scanning or QR code
- Configure and test via Ajax mobile or desktop apps
Reliability & Supervision
- Two tamper buttons for enclosure opening and detachment
- Device authentication to prevent spoofing
- Short‑circuit protection on the Fibra line
- Communication loss detection (as fast as 36 seconds depending on settings)
- Regular polling for real‑time device status
- Instant malfunction notifications to PROs and users
Compliance
- EN 50131 Grade 2
- PD 6662:2017
- INCERT
- NFA2P
- Operating temperature: −10 °C to +40 °C
- Operating humidity: up to 75%
- Dimensions: 90.5 × 21 × 18.5 mm
- Colours: White, Black
Specifications
| Product Type | Wired opening detector |
| Sensitive Elements | 2 × reed switches |
| Opening Detection | Magnet can be installed on left or right side |
| Reed Switch Resource | Up to 2,000,000 operations per reed switch |
| Magnets | Two magnets included (big and small) |
| Third-Party Detector Input | NC contact type (no power output) |
| Chime Feature | Yes, requires Ajax siren |
| Communication Technology | Fibra wired communication with encryption, TDMA, two-way communication |
| Communication Range | Up to 2,000 m using U/UTP Cat.5 cable |
| Tamper Protection | Two tamper buttons (detachment + enclosure opening), holding screws, short-circuit protection |
| Power Supply | 5–30 V⎓ via Fibra line |
| Power Consumption | Up to 0.036 W |
| Operating Temperature | -10 °C to +40 °C |
| Operating Humidity | Up to 75% |
| Dimensions | 90.5 × 21 × 18.5 mm |
| Weight | White: 17 g, Black: 15 g |
| Colours | White, Black |
| Protection Class | IP50, IK04 |
| Complete Set | Superior DoorProtect Fibra, big magnet, small magnet, installation kit, quick start guide |
| Compliance | EN 50131 Grade 2, PD 6662:2017, INCERT, NFA2P |
