Superior H2DAI Series
AI‑powered NVR series with 4K HDMI output, dual hot‑swappable HDDs, JetSparrow encrypted streaming, and model options up to 32 channels.
Selected Model
Name: —
SKU: —
Online pricing for this product is unavailable due to supplier restrictions. Please contact us for an authorised quote.
Superior H2DAI Series
The Ajax Superior H2DAI Series is an advanced line of AI‑powered network video recorders designed for high‑performance surveillance across commercial, industrial, and enterprise environments. With support for up to 32 channels, onboard AI analytics, and dual hot‑swappable HDDs, the H2DAI Series delivers powerful, scalable recording for modern security deployments.
According to the datasheet, the series features onboard AI for people, pet, and vehicle detection, enabling intelligent analytics even with older third‑party cameras . Models include non‑PoE variants with dual Gigabit Ethernet interfaces and PoE‑enabled units offering up to 16 PoE ports for direct camera connection .
JetSparrow encrypted streaming ensures instant, secure video transmission and smooth archive navigation, while the built‑in VMS provides full local monitoring through the 4K HDMI output. With support for two hot‑swappable HDDs up to 24 TB each, the H2DAI Series is engineered for long‑term, reliable storage in demanding environments.
Key Features
- 8, 16, or 32 channels depending on model
- Onboard AI for people, pet, and vehicle detection
- Dual hot‑swappable HDD bays (up to 24 TB each)
- 4K HDMI output for local VMS monitoring
- PoE options: 0, 8, or 16 ports
- JetSparrow encrypted streaming for instant playback
- ONVIF/RTSP support for third‑party cameras
- Up to 600 Mbps bandwidth for large deployments
- USB 3.0 + USB 2.0 ports for export and peripherals
- NDAA‑compliant components
How It Works
The H2DAI Series receives video streams from Ajax cameras or third‑party ONVIF/RTSP devices. Onboard AI enhances even basic cameras with intelligent detection capabilities, as described in the datasheet:
“The recorders enable basic cameras to recognize people, pets, and vehicles — with the same accuracy as native Ajax cameras.”
JetSparrow technology ensures encrypted, low‑latency streaming and rapid archive navigation. Two SATA HDD bays provide continuous recording with hot‑swap capability, allowing maintenance without downtime.
The integrated VMS enables on‑site monitoring through the 4K HDMI port, offering multi‑view layouts, event‑driven playback, and instant access to relevant footage.
Installation & Deployment
- Indoor installation with optional rack‑mount kit
- PoE models support direct camera connection
- Non‑PoE models include dual Gigabit Ethernet interfaces
- Add to Ajax system via QR code
- Configure via Ajax mobile or desktop apps
- Automatic camera discovery on the local network
Ideal for enterprise, industrial, and multi‑camera environments requiring reliable, AI‑enhanced recording.
Reliability & Security
- TLS‑encrypted video streams
- Passwordless camera authentication
- Secure Boot & signature verification
- Real‑time HDD health monitoring
- Redundancy & split‑mode recording
- Exclusive owner access to stored video
Compliance
- NDAA‑compliant components
- CE / RoHS
- IP20 indoor enclosure
Specifications
| Product Type | AI‑powered network video recorder series |
| AI | Onboard AI for people, pet, and vehicle detection |
| HDD Support | 2 × hot‑swappable SATA bays (up to 24 TB each) |
| Channel Options | 8, 16, or 32 channels depending on model |
| PoE Options | 0, 8, or 16 PoE ports depending on model |
| HDMI Output | 4K HDMI |
| Ethernet | 1 × or 2 × RJ45 (up to 1 Gbps depending on model) |
| USB Ports | 1 × USB 3.0, 2 × USB 2.0 |
| Decoding | 4K decoding, multi‑camera playback |
| Video Codec | H.265 / H.264 |
| JetSparrow | Encrypted low‑latency streaming |
| Bandwidth | Up to 600 Mbps incoming / 600 Mbps outgoing |
| Operating Temperature | 0 °C to +50 °C |
| Operating Humidity | Up to 75% |
| Protection | IP20 indoor enclosure |
| Dimensions | 330 × 330 × 44 mm |
| Weight | 3,300 g (without HDDs) |
| Compliance | NDAA, CE, RoHS |
