Can Ajax TurretCam be used outdoors?

Yes. TurretCam is IP65 weather‑resistant and IK08 impact‑rated, making it suitable for both indoor and outdoor installation.

Does TurretCam work without an Ajax NVR?

Yes. TurretCam can operate independently using local microSD storage, or it can integrate with Ajax NVRs and third‑party VMS platforms via ONVIF/RTSP.

How far can TurretCam see at night?

TurretCam includes IR illumination with a range of up to 50 meters (164 feet), providing clear visibility in low‑light and nighttime conditions.

What is the difference between the 2.8 mm and 4 mm lens options?

The 2.8 mm lens provides a wider viewing angle of 100°–110° for general coverage, while the 4 mm lens offers a narrower 75°–85° angle for longer‑distance detail.

Does TurretCam support AI motion detection?

Yes. TurretCam uses AI to recognise people, pets, and vehicles, reducing false alarms and improving event filtering.

Can I view TurretCam on my phone?

Yes. Live video, recordings, and notifications are available through the Ajax mobile and desktop apps, with instant access to events and archive footage.

Is TurretCam easy to install?

Yes. TurretCam is added to the Ajax system via QR code and supports PoE or 12 V DC power. Configuration and maintenance are handled remotely through Ajax apps.

Is Ajax TurretCam NDAA compliant?

Yes. TurretCam uses NDAA‑compliant components and protocols, making it suitable for government and regulated environments.

How secure is TurretCam?

TurretCam uses passwordless mTLS authentication, encrypted video streams, secure export with digital signatures, and multi‑tiered account protection to safeguard privacy.

What storage options does TurretCam support?

TurretCam supports local recording to a microSD card up to 256 GB and can also stream to Ajax NVRs or third‑party VMS platforms.

TurretCam

Wired AI‑powered IP turret camera with IR illumination, True WDR, microphone, and NDAA‑compliant components.

Resolution

5 MP 8 MP

Lens

2.8 mm 4 mm

Selected Model

Name: —

SKU: —

Online pricing for this product is unavailable due to supplier restrictions. Please contact us for an authorised quote.

Available Colours

View Datasheet (PDF)

TurretCam — Original Series

Ajax TurretCam is a wired AI‑powered IP security camera designed for reliable indoor and outdoor surveillance. Available in 5 MP and 8 MP variants with 2.8 mm or 4 mm fixed lenses, TurretCam delivers sharp, high‑definition video with True WDR, long‑range IR illumination, and advanced object recognition. Its compact turret form factor reduces glare and reflections, making it ideal for both wall and ceiling installations.

With NDAA‑compliant components, encrypted video streaming, and user‑controlled access, TurretCam provides dependable, privacy‑focused monitoring for homes, businesses, and commercial environments.

Key Features

5 MP or 8 MP high‑resolution imaging
2.8 mm (100°–110°) or 4 mm (75°–85°) fixed lens options
True WDR for balanced imaging in challenging lighting
IR illumination up to 50 m (164 ft)
Built‑in digital microphone
AI‑powered object recognition (people, pets, vehicles)
Local microSD storage up to 256 GB
PoE 802.3af/at or 12 V⎓ power
ONVIF/RTSP support for third‑party VMS
IP65 weather resistance and IK08 impact protection
NDAA‑compliant components

How It Works

TurretCam combines high‑definition video with advanced AI analytics to deliver accurate, reliable surveillance. Object recognition identifies people, pets, and vehicles, reducing false alarms and ensuring only relevant events are recorded. JetSparrow technology provides instant, secure video streaming and smooth archive navigation.

Video can be stored locally on a microSD card or streamed to Ajax NVRs and third‑party VMS platforms via ONVIF/RTSP. All communication is encrypted, and access to video content is fully controlled by the system owner.

Installation & Deployment

Add to an Ajax system via QR code
Configure via Ajax mobile or desktop apps
Supports ONVIF/RTSP for third‑party VMS
Adjustable motion detection zones
Real‑time device health monitoring
Suitable for indoor and outdoor installations

TurretCam is ideal for residential, commercial, and small‑to‑medium business deployments requiring dependable, AI‑enhanced video surveillance with a compact, low‑profile design.

Reliability & Security

TLS/mTLS encrypted signalling
JetSparrow encrypted video streams
Owner‑controlled access to video content
Secure video export with digital signature verification
Multi‑tiered account protection (passcodes, biometrics, 2FA)
Tamper detection and system health monitoring

Compliance

NDAA‑compliant components
CE / RoHS
IP65 / IK08 enclosure ratings

Specifications

Product Type	Wired AI‑powered IP camera
Sensor Options	5 MP or 8 MP
Lens Options	2.8 mm or 4 mm fixed
Resolution (5 MP)	Up to 2880 × 1620 px @ 25 fps (3K UHD)
Resolution (8 MP)	Up to 3840 × 2160 px @ 20 fps (4K UHD)
Viewing Angle (2.8 mm)	100°–110°
Viewing Angle (4 mm)	75°–85°
IR Illumination	Up to 50 m (164 ft)
Video Compression	H.265, H.264
WDR	True WDR (hardware + software)
AI Features	Object recognition (people, pets, vehicles), motion detection, alarm verification
Audio	Built‑in digital microphone
Local Storage	microSD up to 256 GB
Network	10/100 Mbps RJ‑45, ONVIF/RTSP support
Power Input	PoE 802.3af/at or 12 V DC ±20%
Power Consumption	Up to 8.5 W
Operating Temperature	-30 °C to +60 °C
Operating Humidity	Up to 90% RH
Protection	IP65, IK08
Dimensions	103 × 98 × 98 mm
Weight	475 g
Cybersecurity	mTLS authentication, TLS‑encrypted streams, secure export with digital signature
Compliance	CE, RoHS, NDAA
