TurretCam (5 MP/4 MM)
A 5MP TurretCam with a 4mm lens for tighter coverage, True WDR, IR up to 50 m, and AI object recognition.
Online pricing for this product is unavailable due to supplier restrictions. Please contact us for an authorised quote.
Available Colours
TurretCam (5 MP / 4 mm)
Overview
TurretCam (5 MP / 4 mm) is built for scenarios where a more focused field of view is required. With up to 2880 × 1620 px resolution and a 4 mm fixed lens delivering a 75°–85° viewing angle, it is ideal for entrances, gates, and medium‑distance monitoring.
Key Features
- 5 MP CMOS sensor with up to 2880 × 1620 px resolution
- 4 mm fixed lens with 75°–85° viewing angle
- IR illumination up to 50 m
- True WDR for challenging lighting conditions
- AI‑powered detection of people, pets, and vehicles
- JetSparrow streaming for fast live view and archive navigation
- microSD support up to 256 GB
- IP65 and IK08‑rated metal enclosure
Ideal Applications
- Driveways and vehicle gates
- Narrow corridors and focused monitoring zones
- Small commercial entrances
Integration
Supports Ajax NVR, Ajax apps, and third‑party VMS via ONVIF/RTSP, enabling flexible integration into existing video systems.
Specifications
| Resolution | 5 MP (up to 2880 × 1620 px) |
| Sensor | CMOS |
| Lens | 4 mm fixed |
| Viewing Angle | 75°–85° |
| Frame Rate | Up to 25 fps (3K UHD) |
| IR Illumination | Up to 50 m |
| Dynamic Range | True WDR |
| Video Codec | H.264 / H.265 |
| Audio | Built-in digital microphone, G.711 codec |
| Storage | microSD up to 256 GB |
| Network | 10/100 Mbps Ethernet (RJ-45), ONVIF, RTSP |
| Protection | IP65, IK08 |
| Operating Temperature | −30 °C to +60 °C |
| Power | PoE 802.3at/af, 12 V DC |
