AXIS Camera Station S2212 Mk II Standalone Appliance
Silent all‑in‑one 12‑channel standalone appliance with integrated PoE switch, 4 TB surveillance‑grade storage, Windows IoT, and advanced Axis cybersecurity.
$5704
View Datasheet (PDF)AXIS Camera Station S2212 Mk II Standalone Appliance
AXIS S2212 Mk II is a silent, all‑in‑one standalone appliance for up to twelve video channels. It includes an integrated PoE switch, 4 TB of surveillance‑grade storage, and AXIS Camera Station Pro licenses tied to the hardware. This all‑in‑one standalone appliance is silent and won't disturb local operations, making it ideal for office and customer‑facing environments.
Key Features
- 12‑port PoE switch (IEEE 802.3at Class 4, 180 W total)
- 4 TB surveillance‑grade HDD with one free expansion slot
- Intel Core i3 processor and 16 GB DDR5 memory
- Windows 11 IoT Enterprise LTSC 2024
- Supports up to 12 video channels and access control
- Includes 12 AXIS Camera Station Pro licenses
- Silent operation for low‑noise environments
- TPM 2.0 (FIPS 140‑2 Level 2), secure boot, signed firmware
- 5‑year hardware warranty
How It Works
The appliance powers and connects up to twelve AXIS cameras directly through its integrated PoE switch. Video is stored on a surveillance‑grade HDD, with a second slot available for expansion. Windows IoT and AXIS Recorder Toolbox streamline setup, monitoring, and maintenance. TPM‑backed encryption and secure boot protect the operating system and recording drives.
Installation & Placement
- Desktop or shelf‑mounted
- Suitable for offices, retail, reception areas, and small commercial sites
- Operating range: 0 °C to 40 °C
- Includes rack ears and external power adapter
Reliability & Cybersecurity
- TPM 2.0 with FIPS 140‑2 Level 2 certification
- Secure boot and signed switch firmware
- Encrypted OS and recording drives
- AXIS Recorder Toolbox for diagnostics and updates
Compliance
- UL/CUL, BIS, CE, KC, VCCI, RCM, BSMI, FCC, NOM
- EN 55035, EN 55032 Class A
- IEC/EN 62368‑1
- TAA compliant
- NDAA Section 889
Specifications
| Product Type | Standalone 12‑channel NVR appliance |
| Integrated PoE Switch | 12 × PoE ports (IEEE 802.3at Class 4), 180 W total budget |
| Storage | 4 TB surveillance‑grade HDD (1 × 4 TB installed, 1 free slot) |
| Recording Capacity | Up to 128 Mbps total recording rate |
| Processor | Intel Core i3 |
| Memory | 16 GB DDR5 |
| Operating System | Windows 11 IoT Enterprise LTSC 2024 |
| Graphics | Intel UHD Graphics |
| USB Ports | 2 × USB 3.2 (front), 2 × USB 2.0 (rear) |
| Network Uplink | 1 × 1 Gbps LAN (switch), 1 × 1 Gbps LAN (server) |
| Video Outputs | 2 × HDMI 2.1 |
| Audio | Universal audio jack (front) |
| Cybersecurity | TPM 2.0 (FIPS 140‑2 Level 2), secure boot, signed firmware, encrypted OS and recording drives |
| Power Input | 100–240 V AC, 50/60 Hz, max 270 W |
| Operating Temperature | 0 °C to 40 °C |
| Operating Humidity | 10–90% RH (non‑condensing) |
| Dimensions | 330 × 230 × 78 mm |
| Weight | 5.8 kg |
| Compliance | UL/CUL, BIS, CE, KC, VCCI, RCM, BSMI, FCC, NOM, EN 55035, EN 55032 Class A, IEC/EN 62368‑1, TAA compliant, NDAA Section 889 |
